Details

---

The Skyworth QM192AFCD‑660‑72 is a bifacial glass‑glass solar module rated at 660 Wp, designed for large‑scale solar farms with high efficiency and durability. It supports up to 1500 VDC system voltage, has a module efficiency of about 24.4%, and uses half‑cut mono crystalline silicon cells for improved performance.

🔑 Key Specifications

• Model: QM192AFCD‑660‑72

• Manufacturer: Skyworth (Shenzhen Qiming Photovoltaic Technology Co., Ltd.)

• Rated Power Output: 660 Wp

• Module Efficiency: ~24.4%

• Cell Type: Half‑cut mono c‑Si cells (144 cells)

• Construction: Bifacial, Glass/Glass design with silver frame

• Maximum System Voltage: 1500 VDC

• Series Fuse Rating: 30 A

• Cable Length: +400/‑200 mm (factory standard)

• Dimensions/Weight: Approx. 2.0 kg gross weight per unit (packaging spec)

• Ingress Protection: Designed for outdoor durability (IP65/IP66 depending on system design)

⚙️ Performance Features

• Bifacial Technology: Generates power from both front and rear sides, increasing energy yield especially in reflective environments (e.g., solar farms with light‑colored ground).

• Glass/Glass Lamination: Provides higher mechanical strength, better fire resistance, and longer lifespan compared to glass/backsheet modules.

• High Efficiency: 24.4% module efficiency places it among Tier‑1 level panels, suitable for utility‑scale projects.

• Durability: Certified for operation up to 1500 VDC, ensuring compatibility with modern large‑scale inverters and string configurations.

📌 Certification & Compliance

• TÜV Rheinland Conformity Certificate (valid for EU Low Voltage Directive compliance).

• Output Range: 610–675 Wp depending on variant, with the 660 Wp model being standard.

• Applications: Utility‑scale solar farms, EPC projects, and high‑capacity installations
